TrueTemp® TC130 Series Temperature Control Unit
The TrueTemp® TC130 Series Water Temperature Control Unit is AEC’s most advanced temperature control solution, designed for plastics processing and other industrial manufacturing applications requiring precise process temperature management. Powered by the advanced M5 controller, the TC130 delivers accurate, responsive temperature control while providing enhanced monitoring, diagnostics, and system intelligence.
Featuring innovative technologies such as Pressure Adaptive Technology, Cascade Control, predictive maintenance monitoring, USB data logging, and remote monitoring capabilities, the TC130 Series helps minimize unplanned downtime, improve process stability, and optimize production performance. Its advanced functionality and flexible configuration options make it an ideal solution for processors seeking maximum control, reliability, and operational efficiency.
REQUEST A QUOTE Find a rep
- Pressure adaptive technology
- State-of-the-art M5 controller
- Digital pressure transducers
- Contactor cycle life indicator
- USB data logging for improved analysis & troubleshooting
- Automatically cycles between half & full heat
- Better controls
- Predictive maintenance
- Expanded warranty
- Compact design with easy-access side panels for rapid maintenance
- Programmable auto vent sequence to automatically vent air from the system at start-up
- Independent high temperature safety thermostat to protect from heater overload
- Motor branch circuit overcurrent/overload protection
- Integrated cooling solenoid valves for efficient unit cooling
- 9 kW heater
- Dual circuit immersion heater with IEC contactors
- Standard operating temperature up to 250° F (121° C)
- NEMA 12 electrical enclosure
- OPC UA / Euromap 82.1
- VNC
- Ethernet – Standard
- 150 psig (10.3 bar) pressure relief valve
- Silicon carbide / carbon pump seal to maximize pump life
- 3/4” NPT water supply connection, 1 1/2” NPT process connections; valve size matches drain size
- Modbus TCP
- Quick cool for rapid unit cooling
- Non-fused lockable rotary through door disconnect
- 1 year warranty – factory labor
- 2 year warranty – parts
- 3 year warranty – controller
- Remote control
- 12 kW, 18 kW, or 24 kW heater options, 36 kW & 48 kW for upright units
- Maintained START/STOP switch
- Closed loop heat exchanger
- General fault audible/visual alarm to alert operators of unit issues
- Pressure regulator/relief valve for water supply
- Remote setpoint & analog retransmission
- Mold purge
- Y-strainer to protect unit from high particulate fluid
- 300°F (149°C) operating temperature
- Manual bypass
- Modbus RS-485
- MiVue® – Digital Solutions Platform
The TC130/131 TCU requires only minimum pressure based on desired temperature set point instead of a predefined 15 or 55 psi.
If a TCU experiences a momentary or even sustained pressure drop, the unit will temporarily decrease temperature until pressure is restored instead of instantly shutting down.
AEC is proud to offer Quick Ship options for the products listed below. Click on the product order button below to contact us only or call our Inside Sales Team at (262) 641-3987 for help selecting the right product or to place an order for any of the products listed below.
There are no Quick Ship products found from the current category.
Intelligent | Predictive | Reliable
-
Smart Controls for a Smarter Facility
Pressure Adaptive Technology, Contactor Cycle Life Indication, Cascade Controls
-
Ergonomic
TC131 Upright configuration available for more ergonomic orientation
